Information
The SPAA05 range of GPS based Antenna
Alignment Tools is specially designed to improve
the nominal antenna Bearing (azimuth) of GSM,
DCS and UMTS Mobile cellular networks.
Two version are available at this time. The standard
SPAA05 and the -all new- SPAA05-NEX
Both systems feature -easy to use- antenna
mounting and back-office software solutions.
Main Functions.
The SPAA05 and SPAA05-NEX models measures, in
real time, the exact antenna bearing within 2
minutes after switching on the system. When using
the full software -100 count- an accuracy of 0,5
degrees RMS can be achieved.
At this moment a number of networks operators
have not specified their needs for such very high
accuracy yet, however, comparison with existing
antennas on many sites show clearly that most
installation companies cannot achieve the current
requirements of ± 3° or ± 5° with conventional
methods like Magnetic Compass or Triangulation
Measurements.
For that reason most European Network operators
have made the use of our SPAA05 tools as their
standard.
How to Use it.
A simple 5 step procedure on site will measure and
store the individual antenna Bearing and other
important site information. Our file encryption
process secures the measurement results incl.
Time, date and position stamping.
Back-office processing takes only a few minutes per
site.
|
Step 1.
Access Roof or tower and
select the correct antenna.
|
Step 2.
Attach the antenna clamp and
switch on the SPAA05.
|
Step 3.
Take a measurement,
adjust the antenna
and store the data
Sector by sector.
 |
Step 4.
Send the test results
to your office. |
|
Step 5.
Print the test results and forward to you
customer.
|
|
